Product Detail
1\Quick Details
Place of Origin: China (Mainland) Brand Name: Kingdream,CS,Noryke Model Number: 3 Wings stepped drag bit
Type: Drill Bit Machine
PDC Drag Bits
PDC bit/PDC drag bit/bit for water well drilling
We can supply different diameter of 2-wings drag bit, 3-wings drag bit, 4-wings drag bit, and 6-wings drag bit.
PDC Drag bit are manufactured from forged high quality alloy steel and premium PDC cutter insert, plus state of art welding technology and multiple precision heat treatment to provide highest penetration rate and longest lifespan at roughest condition.
Product Feature:
PDC drag bits are designed for medium to hard formation and are used in areas that contain a lot of rock and also in the oil field.
PDC drag bit is also widely used for large diameter drilling, such as water well, exploration project and others.
Product Specifications:
Size | Type Pin | Wt. (lbs.) |
1 3/4" - 2 1/2" | AW, A-Rod | 2 |
2 5/8" - 2 7/8" | AW, A-Rod | 2 1/2 |
2 3/4" - 3 1/4" | 3THD/4THD N-Rod, 2" IF | 4 |
3 3/8" - 3 3/4" | 3THD/4THD N-Rod, 2"IF | 4 1/2 |
3 7/8" - 4 3/4" | 2 3/8" API Pin | 6 |
4 7/8" - 5 1/8" | 2 3/8" API Pin | 7 |
5 1/4" - 5 1/2" | 2 3/8" API Pin | 8 |
4 5/8" - 5" | 2 7/8" API Pin | 10 |
5 1/8" - 5 1/2" | 2 7/8" API Pin | 11 |
5 5/8" - 6 1/4" | 3 1/2" API Pin | 18 |
6 1/2" - 6 3/4" | 3 1/2" API Pin | 19 |
7" - 7 1/2" | 3 1/2" API Pin | 21 |
7 5/8" - 8" | 3 1/2" API Pin | 23 |
